Motorola® SURFboard® SB6121 DOCSIS 3.0 Cable Modem Item # 902317 OfficeMax # 23354157

Motorola® SURFboard® SB6121 DOCSIS 3.0 Cable Modem
Click to View Gallery

Write the first review

Recommended Alternatives

Description

High-speed connection to the Internet

  • Equipped with Ethernet connectivity.
  • Provides a maximum download speed of 171.537 Mbps and upload speed of 131.072 Mbps.
  • Front panel status lights.  Let you quickly see modem status for power, communications and errors.
  • DOCSIS 3.0 technology.  Permits the addition of high-speed data transfer to an existing cable TV system.
  • Power supply and Ethernet cable are included.

Back to Menu

Product Details

Item # 902317
Manufacturer # 575319-019-00
Eco-conscious helps save energy
brand name Motorola
height 5.2 in
maximum upload speed 131.072 Mbps
telephone cord included no
modem standard DOCSIS 3.0
width 1.7 in
operating system compatibility Windows XP Service Pack 2; Windows Vista Service Pack 1; Windows 7; Mac 10.4+ (Ethernet connection only); Linux (Ethernet connection only); UNIX (Ethernet connection only)
depth 5.2 in
maximum download speed 171.537 Mbps
eco-label/standard ENERGY STAR; RoHS
connector type Ethernet
manufacturer Motorola
warranty length 2-year limited
internal/external External

Back to Menu

Back to Menu

Back To Top

From the Manufacturer|Powered by Webcollage

Thank You Is the information in this section helpful? Yes / No

Features




Demo Video

{"runtimePoster":{"runtimeSrc":{"height":1080,"width":1920,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg.poster.jpeg"},"isAdaCompliant":false,"src":{"height":1080,"width":1920,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg.poster.jpeg"},"sources":[{"height":1080,"width":1920,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg.poster.jpeg"}]},"duration":78,"assetWrapper":"root","customPoster":{"runtimeSrc":{"height":540,"width":960,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg.web.v1.960.jpg"},"isAdaCompliant":false,"src":{"height":540,"width":960,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg"},"sources":[{"height":540,"width":960,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-a6259499-b08e-455c-8986-8ec82d3e6cfd.jpeg.web.v1.960.jpg"}]},"caption":"","isAdaCompliant":false,"src":{"height":1080,"width":1920,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-5b27bf6b-5198-49d0-8aeb-6f24b322c30c.mp4"},"showVideoCaption":true,"sources":[{"height":540,"width":960,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-5b27bf6b-5198-49d0-8aeb-6f24b322c30c.mp4.flash.flv","profile":"FLASH"},{"height":270,"width":480,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-5b27bf6b-5198-49d0-8aeb-6f24b322c30c.mp4.mobile.mp4","profile":"MOBILE"},{"height":101,"width":180,"src":"/_cp/products/1336405163138/tab-3d576829-f563-4ed5-8901-fc28aa4b683c/resource-5b27bf6b-5198-49d0-8aeb-6f24b322c30c.mp4.blkbry.mp4","profile":"BLKBRY"}]}

Images

{"images":[{"assetWrapper":"image-gallery","runtimeSrc":{"height":2001,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-77a9f41e-057e-49aa-9421-e6d47cea0f61.jpg.web.v1.960.jpg"},"isAdaCompliant":false,"src":{"height":2001,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-77a9f41e-057e-49aa-9421-e6d47cea0f61.jpg"},"sources":[{"height":2001,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-77a9f41e-057e-49aa-9421-e6d47cea0f61.jpg.w960.jpg","profile":"W960"},{"height":1000,"width":480,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-77a9f41e-057e-49aa-9421-e6d47cea0f61.jpg.w480.jpg","profile":"W480"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":1609,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-07712d3f-faa6-4498-9fa2-eb6bdd688956.jpg.web.v1.960.jpg"},"isAdaCompliant":false,"src":{"height":1609,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-07712d3f-faa6-4498-9fa2-eb6bdd688956.jpg"},"sources":[{"height":1609,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-07712d3f-faa6-4498-9fa2-eb6bdd688956.jpg.w960.jpg","profile":"W960"},{"height":804,"width":480,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-07712d3f-faa6-4498-9fa2-eb6bdd688956.jpg.w480.jpg","profile":"W480"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":1200,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-60363a25-7bdd-4ca7-9ee6-13e9064ceff5.jpg.web.v1.960.jpg"},"isAdaCompliant":false,"src":{"height":1200,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-60363a25-7bdd-4ca7-9ee6-13e9064ceff5.jpg"},"sources":[{"height":1200,"width":960,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-60363a25-7bdd-4ca7-9ee6-13e9064ceff5.jpg.w960.jpg","profile":"W960"},{"height":600,"width":480,"src":"/_cp/products/1336405163138/tab-4170512a-fe5a-4915-96f8-4a56e502937c/resource-60363a25-7bdd-4ca7-9ee6-13e9064ceff5.jpg.w480.jpg","profile":"W480"}]}]}

Virtual Tour

{"tourViews":[{"viewImage":{"assetWrapper":"tour","runtimeSrc":{"height":564,"width":540,"src":"/_cp/products/1336405163138/tab-2306d874-d567-4a13-b993-feba20891d02/resource-7ffef411-50df-4754-831d-597958550bbe.jpg.web.v1.jpg"},"isAdaCompliant":false,"src":{"height":564,"width":540,"src":"/_cp/products/1336405163138/tab-2306d874-d567-4a13-b993-feba20891d02/resource-7ffef411-50df-4754-831d-597958550bbe.jpg"},"sources":[{"height":564,"width":540,"src":"/_cp/products/1336405163138/tab-2306d874-d567-4a13-b993-feba20891d02/resource-7ffef411-50df-4754-831d-597958550bbe.jpg.w960.jpg","profile":"W960"},{"height":501,"width":480,"src":"/_cp/products/1336405163138/tab-2306d874-d567-4a13-b993-feba20891d02/resource-7ffef411-50df-4754-831d-597958550bbe.jpg.w480.jpg","profile":"W480"}]},"hotspots":[{"hotspotX":0.3208955223880597,"captionFromAttr":"Power Signal","direction":"right","hotspotY":0.3535714285714286},{"hotspotX":0.16791044776119404,"captionFromAttr":"Receive Signal","direction":"right","hotspotY":0.41785714285714287},{"hotspotX":0.3208955223880597,"captionFromAttr":"Send Signal","direction":"right","hotspotY":0.4785714285714286},{"hotspotX":0.17164179104477612,"captionFromAttr":"Online Signal","direction":"right","hotspotY":0.5428571428571428},{"hotspotX":0.3208955223880597,"captionFromAttr":"Link Signal","direction":"right","hotspotY":0.6},{"hotspotX":0.8805970149253731,"captionFromAttr":"Ethernet Connection","direction":"left","hotspotY":0.19642857142857142},{"hotspotX":0.8880597014925373,"captionFromAttr":"Coaxial Cable Connecction","direction":"left","hotspotY":0.44285714285714284},{"hotspotX":0.8731343283582089,"captionFromAttr":"Power Connection","direction":"left","hotspotY":0.7678571428571429}]}],"ipiCompatible":false}
  1. Power Signal
  2. Receive Signal
  3. Send Signal
  4. Online Signal
  5. Link Signal
  6. Ethernet Connection
  7. Coaxial Cable Connecction
  8. Power Connection
Image/Features

Power Signal

Receive Signal

Send Signal

Online Signal

Link Signal

Ethernet Connection

Coaxial Cable Connecction

Power Connection
Product Tour
Click to Start

Specifications



GENERAL

CPE Network Interface10/100/1000Base-T Ethernet (RJ-45)
Data ProtocolTCP/IP
Dimensions5.24 in H x 5.24 in W x 1.65 in D
(133 mm x 133 mm x 42 mm)
Power9W (nominal)
Input PowerNorth America: 105 to 125 VAC, 60 Hz
Outside North America: 100 to 240 VAC, 50 to 60 Hz
RegulartoryRoHS compliant, ENERGY STAR V2 , COC V3, Compliant per the
“Code of Conduct on Energy Consumption of Broadband
Equipment”, CMM, MEPS



ENVIRONMENTAL

Operating Temperature32 F to 104 °F (0 °C to 40 °C)
Storage Temperature–22 °F to 158 °F (–30 °C to 70 °C)
Operating Humidity5 to 95% R.H. (non-condensing)



DOWNSTREAM

Modulation64 or 256 QAM
Capture Bandwidth100 MHz (edge to edge)

Maximum Theoretical Data Rate**

DOCSIS: 171.537 Mbps (4 channels) / 42.884 (single channel)
@ 256 QAM at 5.36 Msym/s

ProvisioningSupports IP addressing using IPv4 and/or IPv6 (dual stack)



UPSTREAM

Maximum Channel Rate**DOCSIS: 131.072 Mbps (4 channels) / 32.768 Mbps (single channel):
@ 128 QAM at 6.4 MHz
Frequency RangeDOCSIS 5-42 MHz (edge to edge), EuroDOCSIS and
optional DOCSIS 5 to 65 MHz (edge to edge)
CompatibilityPC: 90496, Pentium, or later; Windows Vista™, 2000, XP or 7 or Linux® with Ethernet connection (older versions of Windows, although not specifically supported, will work with this cable modem)
Macintosh: Power PC or later; OS 9 or higher, Ethernet connection
UNIX: Ethernet connection
Home Networking: Ethernet router or wireless access point
